E360 V-belt
[In stock and available for immediate pickup or delivery across Canada/USA]
International orders, please contact us.
Brand: THREE FIVE
Model: E360
Made in Thailand
Information
THREE FIVE Classic and Dual Brand V-belts are made with high performance rubber compounds to perform in the harshest operating conditions. Pre-stretched polyester cord is specially bonded within the rubber core using a proprietary formula to provide extended flex life.
Engineered and manufactured with a durable outer covering, these belts also provide for quiet, low vibration operation in a variety of industrial applications. Improved strength and flexibility also help to prolong the service life of your motor. Contact us directly for any unlisted sizes.
- Premium rubber base delivers exceptional belt life
- Meets RMA standards for Oil and Heat Resistance and Static Conductivity
- High tensile strength allows for greater power transmission applications
Common Applications
- Industrial machinery
- Material handling equipment
- Ongoing facility maintenance applications
- Other light or standard duty drives
Specifications
| Outside Length | 363 (in) |
| Width (a) |
1-1/2 (in); 38 (mm) |
| Height (b) | 1 (in); 25.4 (mm) |
| Angle (ϴ) | 40 (°) |
| Approx. Weight | 20.44 (lbs); 9273 (g) |
All dimensions are nominal
